Category: DSI Construction
-
DSI Multitouch construction – Part 8
In the never ending quest to get better blob tracking on my touch screen I decided to add more cameras. A few months ago I added a second camera but they didn’t quite cover the whole screen – there was about an inch gap in the centre of the screen. I didn’t want to use…
-
DSI Multitouch construction – Part 7
Well its been a while since I posted an update on my DSI coffee table. It is pretty much complete now. The last thing I have to do is get a piece of scratch resistant plexiglas for the table top to create a single seamless top. I would also like to get black perspex for…
-
DSI Multitouch construction – Part 6
Here is a small update on the current state of my coffee table. Its been a nearly a year now since I first started and I’m still slowly working on it. Recently I decided to add some touch sensitive hardware buttons at the edge of the screen. I researched some different ways of doing this…
-
DSI Multitouch construction – Part 5
Here is some more updated photos of the coffee table. I wanted to post some shots up before I head over to Japan in a few days. I managed to get it out of my bedroom and into the lounge for some better shots. Note that the top and sides are not the final. Currently…
-
DSI Multitouch construction – Part 4.5
This is just a small update with a few new photos… I’ve have now painted the table top black, I used a matte black spray paint (because I think its easier to get an even colour with) and then went over the top with a clear gloss. A also made a temporary top cover and…
-
DSI Multitouch construction – Part 4
Its been a while since I posted an update on my Multitouch coffee table. I am still working on it, just little bits at a time so no significant progress has been made worth posting. But here are some more photos of the progress. I will have some more recent shots up later in the…
-
DSI Multitouch construction – Part 3
Over the weekend I made a lot more progress on my multitouch coffee table. I also discovered some issues – firstly the original backlight emits way too much infra-red light so I am going to have to make a custom one out of ultra-bright LED strips, and secondly I don’t seem to be getting any…
-
DSI Multitouch construction – Part 2
Here are some more shots of the work in progress of the DSI Multitouch Coffee table I’m building. Last week the Endlighten arrived. This wasn’t the easiest to acquire – in Australia the only option really was to buy a full sheet which would have cost $1000+. The best place to get cut-to-size acrylic is…
-
32″ DSI Multitouch coffee table construction – Part 1
For a while now I have been planning a 32″ multitouch coffee table. DSI uses a special acrylic which when lit from the edges distrubutes even illumination across the panel. Over the last few weeks I have been collecting bits and pieces and this weekend I started making the top for the table. Photos below.…
